16-22+ Camaro 2.0T LTG Forged 86mm Bore STD 9.5:1 Piston Kit, CP Carrillo

CP-Carrillo is proud to introduce FORGED pistons for the GM Ecotec 2.0 L 4 cylinder turbocharged engine. After hearing of many reports of cracked skirts in low mileage stock engines, we now offer an alternative to the factory pistons. Pistons are available in standard bore (86MM) at the stock compression ratio of 9.5:1, for a stock length rod. The wrist pin size is 22 MM (.866”) to improve the parts durability, but the stock pin bores will need to be bushed smaller or use an aftermarket rod. (CP-Carrillo offers a rod with pin end width at 0.950). Pin Boss span is 1.030 Includes a 1mm x 1.2mm x 2.8mm ring package to take advantage of the availability of upgraded aftermarket offerings.

• Weight 5.1300
• Part Type Pistons
• Make Cadillac, Chevrolet, GM
• Engine LTG 2.0L Turbo
• Compression Ratio 9.5:1
• Item Weight 350 g
• Bore Diameter 86mm
• Pin Size 0.866" / 22mm
• Included Ring Set CPN-3386
• Dome cc -1.7 cc
• Compression Height 32mm
• Manufacturer CP Pistons
• Stroke 86mm
• Rod Length 6.004" / 152.5mm
• Compression Ratio Range 9.0:1 - 10.0:1
• Bore Oversize Standard Bore
• Engine Head LTG 2.0L Turbo
• Rod Length Oversize Standard Length
