C5 / C6 Corvette Alternator, 220 amp, 12V, S Series Billet Racing, Black Anodized

Alternators and Generators, S Series Billet Racing Alternators, 12 V, 240 amps, Black Anodized, Serpentine Pulley, Chevrolet, 6.0L, 6.2L, 7.0L, Each

Manufacturer's Part Number:
B13969240B
Part Type:
Alternators and Generators
Product Line:
MechMan S Series Billet Racing Alternators
Summit Racing Part Number:
MEH-B13969240B
UPC:
00817301022675
Remanufactured:
No
Advertised Amperage Output:
240 amps
Color:
Black
Coating Type:
Anodized
Voltage Compatibility:
12
One-Wire Capable:
No
Pulley Included:
Yes
Pulley Style:
Serpentine
Regulator Included:
Yes
Alternator Regulator Location:
Internal
Belt Included:
No
Alternator Brackets Included:
No
Quantity:
Sold individually.
Notes:
Will not charge at factory idle speed, must raise idle RPM to 800-850.

The MechMan S Series of 6-phase billet racing alternators offers incredible output in a compact and durable package. Highly efficient, these units use less horsepower per kW than conventional 3-phase alternators. They feature 12 diodes, twin rectifier plates, and outstanding airflow to ensure long service life, even in severe conditions. The alternators are available for a broad range of domestic and import applications in 170 or 240 amp configurations—as well as a variety of finishes. (The 170 amp S Series unit uses a stock diameter pulley, making it perfect for high-rpm and racing use.)
