GForce Performance Engineering C8 Corvette OUTLAW Axles are a direct replacement for factory half-shafts and are designed for C8 Corvettes making big power with serious demands on their driveline. The added strength makes them ideal for use with the Lingenfelter MAGNUSON TVS2650 Chevrolet C8 Corvette DI 700 Horsepower Supercharger Package.
The GForce Performance Engineering C8 Corvette OUTLAW Axles have been engineered with premium CV joints. The Outlaw CV joints maintain a 108mm design but feature an upgraded alloy on the billet machined internals. Each CV joint receives an isotropic surface finish for a mirror-like polish. The surface finishing provides smoother operation for the CV joint which dramatically reduces heat and premature wear and aids in grease migration. In addition, each Outlaw axle uses premium fasteners for the industry’s strongest CV axle bolts.
The GForce Outlaw Axles remains the leader of IRS axles with the largest diameter axle bars available, the only 31-spline axle bar, and CV on the market, and now with the most durable CV joint possible.
- Anti-Wheel Hop Technology
- Direct Bolt-In Fit and Finish
- 31-Spline Severe-Duty OUTLAW CV Joints
- Isotropic Surface & Internal Finish on CV Joints
- Upgraded Premium CV Joint Fasteners
- 1-Piece Outer Stubs
- Aircraft Grade Certified Alloys
- CNC-Machined
- Powder Coated Axles For Corrosion Protection
- Black E-coat Finish on Outer Stubs to Protect Against Harsh Conditions without Impeding Spline Engagement
GForce Performance Engineering C8 Corvette OUTLAW Axles are machined from proprietary aerospace billet alloy and they feature an upgraded 31-spline axle bar and 31-spline billet machined CV joints. The additional splines offer more spline engagement and allow for larger diameter axle bars equaling unparalleled strength. In addition to more spline engagement, the billet machined 31-spline CVs provide more travel and increased operating angle than OEM CV joints.
The GForce Performance Engineering C8 Corvette OUTLAW Axles axles also include 1-piece CNC-machined billet steel outer stubs. Machined from a single piece of billet steel, GForce outer 1-piece stubs are the strongest stub design period.
Each component of the GForce Performance Engineering C8 Corvette OUTLAW Axle is meticulously designed, machined, and assembled by GForce in our Kansas-based facility. Because we carefully control each process, hand-build each axle assembly, and only use premium materials, GForce axles boast an unrivaled warranty.
IMPORTANT | GForce Performance Engineering C8 Corvette OUTLAW Axles were manufactured based on OEM suspension. Aftermarket shocks, control arms, etc. may present clearance issues. If CV boots have clearance issues, low-profile boots can be purchased at an upgraded cost. The low-profile boots reduce the amount of available axle angle in comparison to the standard boots, so they are not ideal for lowered or high axle angle vehicles.
Weight: 70 lbs
Dimensions: 37 × 14 × 7 in
FITMENT | 2020+ C8 Chevrolet Corvette |
