Granatelli 2.25" Mating Flat Flanges - 308522-M

GRANATELLI EXHAUST FABRICATION HARDWARE

BUILD A CLEAN, SERVICEABLE CONNECTION FOR YOUR EXHAUST SYSTEM.

The Granatelli Motor Sports 308522-M Mating Flat Flange is a precision-machined V-band flange designed for custom exhaust, automotive, diesel, marine and industrial fabrication applications.

Designed to work with a compatible mating V-band flange and clamp, this flat flange provides a practical connection point for fabricated exhaust systems where convenient assembly, removal and reinstallation are important.

Why Use a V-Band Flange?

V-band connections provide a convenient solution for creating removable exhaust joints. Instead of using traditional multi-bolt flange connections, a V-band clamp can secure compatible mating flanges together, making the system easier to disassemble when servicing, modifying or replacing exhaust components.

FLAT MATING FLANGE

Simple, Clean & Fabrication-Friendly

The flat mating flange design provides a straightforward connection surface for custom exhaust fabrication. Properly positioned and welded to compatible tubing, the flange can be paired with its corresponding mating flange and V-band clamp to create a convenient serviceable connection.

PRECISION FABRICATION COMPONENT

Precision CNC-Machined V-Band Flange

Granatelli V-band components are designed for fabrication applications requiring accurately machined connection surfaces. The 308522-M can be incorporated into custom exhaust and performance systems where a V-band connection is preferred over a conventional bolted flange.

Ideal Applications

? Custom exhaust systems   •   ? Performance vehicles   •   ? Turbo applications   •   ? Diesel applications   •   ? Race-car fabrication   •   ? Marine applications   •   ? Industrial fabrication   •   ? Custom exhaust projects

APPLICATION & FITMENT

Universal Fabrication Fitment

The 308522-M is a universal fabrication component and is not a vehicle-specific direct-fit replacement. It is intended for custom applications using the corresponding Granatelli V-band components.

Common applications include cars, trucks, diesel vehicles, race vehicles, turbocharged builds, marine systems and industrial equipment.

INDIVIDUAL FLANGE COMPONENT

What's Included

Mating Flat Flange

Part #308522-M



Product Specifications

Brand	Granatelli Motor Sports
Part Number	308522-M
Product Type	Mating Flat V-Band Flange
Flange Style	Flat Mating Flange
Product Category	V-Bands / Exhaust Fabrication
Fitment	Universal Fabrication Application
Condition	New
Country of Manufacture	USA
UPC	802735037968

FITMENT & FABRICATION NOTE: This is a universal V-band fabrication component. Verify the corresponding V-band size, mating flange dimensions, tubing diameter, connection orientation and available clearance before installation. Proper flange alignment and professional welding/fabrication practices are recommended for a secure and reliable exhaust connection.
