Wilwood Brake Kit - Rear - Superlite 4-piston Caliper 14" Rotors C5 & C6 Corvette

97-09 WILWOOD REAR 4-PISTON 14" BIG BRAKE KIT, RED CALIPERS
Wilwood's rear "Big Brake" kits use race technology and components to generate superior stopping power with the durability to survive extreme conditions. Big Brake kits combine high-tech looks with contemporary style that will appeal to the most discriminating Corvette enthusiast. Each kit is a complete bolt-on installation that is fully compatible with the OE master cylinder and ABS while retaining original track width. Fits all C5 & C6 Corvette when using 18" high offset wheels.

The SL4R machined billet four piston radial mount calipers are volume matched to provide the correct front to rear bias when used with the SL6 Superlite front kit. Stainless steel pistons combat heat while stainless bridge wear plates eliminate pad gouging and extend caliper life. The spring-loaded action of the SRS plates also eliminates pad rattle and dampens harmonic vibrations that contribute to pad squeal. BP series brake pads provide response and temperature range matched to the front kits.

The 14" SRP drilled and slotted two piece rotors provides additional balance and stopping power with that "Big Brake" look inside the wheel. Specially machined iron hats bolt to the rotors and contain the drums for operation with the OE parking brake assembly. These hats are plated in a black zinc finish that resists corrosion and completes the high tech look.

Aluminum radial mount caliper brackets with premium grade hardware complete the total car package.

Wilwood stainless steel brake hoses are an option with all brake kits to complete your installation. Kit will require aftermarket wheel spacers of 1/8th" (not included in kit) Rear
